Catalog entry

inv. 53
Salem Harbor
1853
Oil on canvas
26 1/8 x 42 in. (66.4 x 106.7 cm)
Initialed and dated lower right of center (on sail): FHL / 1853

Commentary

This view of Massachusetts Bay south of Cape Ann would be better titled “Off Salem Harbor” as, judging by the distant mainland, the setting is two to three miles offshore. It is possibly Lane’s most fanciful depiction of shipping activity, painted for Nathaniel Silsbee, Jr., part of a prominent Salem shipping family who had as much an eye for ships’ sails and rigging detail as Lane had. The largest ship, at the right, may have been owned by Silsbee or his father.

While the painting has the sun shining from a fixed position, casting shadows on the vessels’ sails with consistency, the wind is blowing from three different directions, to judge from the trims of sails in different parts of the picture. Most puzzling from the viewpoint of seamanship are the clipper ship’s studding sails (stu’ns’ls, as spoken by sailors) acting as extensions of the ship’s squaresails, and which ought to have been taken in before the ship got this close to land. There will be a scramble to take in sail if a sea breeze develops!

The packet ship (with painted false gunports) and the clipper ship would have had nothing to do with Salem Harbor, being too large and deep to berth in that small port. They are properly Boston ships, although they may have had owners who lived in Salem but managed their vessels from offices in Boston. Very much like Gloucester’s merchants, Salem’s counterparts needed a deeper, larger port for their ships. Although Salem Harbor was one of the busiest ports in America in the early nineteenth century, largely due to the China trade, by the time Lane painted it, the town's fortunes were in decline.

The other vessels in this painting would have been more suitable for Salem Harbor. From left to right: a merchant brig, two schooner-rigged boats, a dory, a lumber brig (half-brig rigged), a deeply loaded sloop, and (very distant) a bark. The dory in center foreground has a tow line belayed to a cleat nailed to a broken log—a probable salvage of a wharf piling that broke loose. Also note the date and Lane's initials on the sail of the boat in the middle foreground.

– Erik Ronnberg

[+] See More



Explore catalog entries by keywords view all keywords »

Subject Types:   Harbor Scene »
Vessel Types:   Brig »   //   Brig (Half) »   //   Clipper Ship »   //   Schooner »   //   Sloop »   //   Yawl Boat/ Dory/Wherry »
Massachusetts Locales:   Salem / Salem Harbor »
Activities of People:   Rowing »
Objects:   Flotsam »

Historical Materials
Below is historical information related to the Lane work above. To see complete information on a subject on the Historical Materials page, click on the subject name (in bold and underlined).

[ top]
Other Locales: Salem Harbor, Mass.

Salem Harbor is located on the North Shore of Massachusetts. By Lane's time, it already had a long history as an important seaport. In the mid-nineteenth century, its ship captains had established trade with distant ports in China and the East Indies.

[ top]

In general, brigs were small to medium size merchant vessels, generally ranging between 80 and 120 feet in hull length. Their hull forms ranged from sharp-ended (for greater speed; see Brig "Antelope" in Boston Harbor, 1863 (inv. 43)) to “kettle-bottom” (a contemporary term for full-ended with wide hull bottom for maximum cargo capacity; see Ships in Ice off Ten Pound Island, Gloucester, 1850s (inv. 44) and Boston Harbor, c. 1850 (inv. 48)). The former were widely used in the packet trade (coastwise or transoceanic); the latter were bulk-carriers designed for long passages on regular routes. (1) This rig was favored by Gloucester merchants in the Surinam Trade, which led to vessels so-rigged being referred to by recent historians as Surinam brigs (see Brig "Cadet" in Gloucester Harbor, late 1840s (inv. 13) and Gloucester Harbor (not published)). (2)

Brigs are two-masted square-rigged vessels which fall into three categories:

Full-rigged brigs—simply called brigs—were fully square-rigged on both masts. A sub-type—called a snow—had a trysail mast on the aft side of the lower main mast, on which the spanker, with its gaff and boom, was set. (3)

Brigantines were square-rigged on the fore mast, but set only square topsails on the main mast. This type was rarely seen in America in Lane’s time, but was still used for some naval vessels and European merchant vessels. The term is commonly misapplied to hermaphrodite brigs. (4)

Hermaphrodite brigs—more commonly called half-brigs by American seamen and merchants—were square-rigged only on the fore mast, the main mast being rigged with a spanker and a gaff-topsail. Staysails were often set between the fore and main masts, there being no gaff-rigged sail on the fore mast.

– Erik Ronnberg

References:

1. Howard I. Chapelle, The National Watercraft Collection (Washington, DC: Smithsonian Institution, 1960), 64–68.

2. Alfred Mansfield Brooks, Gloucester Recollected: A Familiar History (Gloucester, MA: Peter Smith, 1974), 62–74. A candid and witty view of Gloucester’s Surinam Trade, which employed brigs and barks.

3. R[ichard] H[enry] Dana, Jr., The Seaman's Friend (Boston: Thomas Groom & Co., 1841. 13th ed., 1873), 100 and Plate 4 and captions; and M.H. Parry, et al., Aak to Zumbra: A Dictionary of the World's Watercraft (Newport News, VA: The Mariners’ Museum, 2000), 95.

4. Parry, 95, see Definition 1.

artwork
Brig "Cadet" in Gloucester Harbor
Fitz Henry Lane
late 1840s
Oil on canvas
17 1/4 x 25 3/4 in.
Cape Ann Museum, Gloucester, Mass., Gift of Isabel Babson Lane, 1946 (1147.a)
Photo: Cape Ann Museum

Detail of brig "Cadet."

Also filed under: "Cadet" (Brig) »

[+]
chart
Chart showing the voyage of the brig Cadet
c.1980
Painting on board
72 x 48 in.
Collection of Erik Ronnberg

Chart showing the voyage of the brig Cadet to Surinam and return, March 10–June 11, 1840.

Image: Erik Ronnberg

Also filed under: "Cadet" (Brig) »   //  Surinam Trade »

[+]
illustration
Full-rigged Brig
Engraving in R. H. Dana, The Seaman's Friend, 13th ed. (Thomas Groom & Co. Publisher, 1873)

Detail of a full-rigged brig is square-rigged at both her masts.

[+]
artwork
Silhouettes of vessel types
Charles G. Davis
Book illustrations from "Shipping and Craft in Silhouette" by Charles G. Davis, Salem, Mass. Marine Research Society, 1929. Selected images
[+]
[ top]

Hermaphrodite brigs—more commonly called half-brigs by American seamen and merchants—were square-rigged only on the fore mast, the main mast being rigged with a spanker and a gaff-topsail. Staysails were often set between the fore and main masts, there being no gaff-rigged sail on the fore mast. (1)

The half-brig was the most common brig type used in the coasting trade and appears often in Lane’s coastal and harbor scenes. The type was further identified by the cargo it carried, if it was conspicuously limited to a specialized trade. Lumber brigs (see Shipping in Down East Waters, 1854 (inv. 212) and View of Southwest Harbor, Maine: Entrance to Somes Sound, 1852 (not published)) and hay brigs (see Lighthouse at Camden, Maine, 1851 (inv. 320)) were recognizable by their conspicuous deck loads. Whaling brigs were easily distinguished by their whaleboats carried on side davits (see Ships in the Harbor (not published)). (2)

 – Erik Ronnberg

References:

1. M.H. Parry, et al., Aaak to Zumbra: A Dictionary of the World's Watercraft Newport News, VA: The Mariners’ Museum, 2000), 268, 274; and A Naval Encyclopaedia (L.R. Hamersly & Co., 1884. Reprint: Detroit, MI: Gale Research Company, 1971), 93, under "Brig-schooner."

2. W.H. Bunting, An Eye for the Coast (Gardiner, ME: Tilbury House: 1998), 52–54, 68–69; and W.H. Bunting, A Day's Work, part 1 (Gardiner, ME: Tilbury House: 1997), 52.

Related tables: Brig »
photo (historical)
Canadian Brig "Ohio" in East Gloucester
c.1910
Photograph

Canadian brig "Ohio" iced in off Reed & Gamage Wharf, East Gloucester.

[+]
photo (historical)
A half brig being towed to the Bay in New York Harbor
George Stacy
1859–60
Photograph
Johnson, H. and Lightfoot, F.S.: Maritime New York in Nineteenth-Century Photographs, Dover Publications, Inc., New York
[+]
illustration
Hermaphrodite Brig
Engraving in R. H. Dana, The Seaman's Friend, 13th ed. (Thomas Groom & Co. Publisher, 1873)

An hermaphrodite brig is square-rigged at her foremast; but has no top, and only fore-and-aft sails at her main mast.

[+]
artwork
Lumber Brig in High Seas
Fitz Henry Lane
n.d.
Oil on canvas
10 1/8 x 16 in.
Cape Ann Museum, Gloucester, Mass., Gift of the Estate of Anne K. Garland, 1990 (2676.00)

Detail of lumber brig.

[+]
artwork
Silhouettes of vessel types
Charles G. Davis
Book illustrations from "Shipping and Craft in Silhouette" by Charles G. Davis, Salem, Mass. Marine Research Society, 1929. Selected images
[+]
[ top]

Schooners in Lane’s time were, with few exceptions, two-masted vessels carrying a fore-and-aft rig having one or two jibs, a fore staysail, gaff-rigged fore- and main sails, and often fore- and main topsails. One variant was the topsail schooner, which set a square topsail on the fore topmast. The hulls of both types were basically similar, their rigs having been chosen for sailing close to the wind. This was an advantage in the coastal trade, where entering confined ports required sailing into the wind and frequent tacking. The square topsail proved useful on longer coastwise voyages, the topsail providing a steadier motion in offshore swells, reducing wear and tear on canvas from the slatting of the fore-and-aft sails. (1)

Schooners of the types portrayed by Lane varied in size from 70 to 100 feet on deck. Their weight was never determined, and the term “tonnage” was a figure derived from a formula which assigned an approximation of hull volume for purposes of imposing duties (port taxes) oncargoes and other official levies. (2)

Crews of smaller schooners numbered three or four men. Larger schooners might carry four to six if a lengthy voyage was planned. The relative simplicity of the rig made sail handling much easier than on a square-rigged vessel. Schooner captains often owned shares in their vessels, but most schooners were majority-owned by land-based firms or by individuals who had the time and business connections to manage the tasks of acquiring and distributing the goods to be carried. (3)

Many schooners were informally “classified” by the nature of their work or the cargoes they carried, the terminology coined by their owners, agents, and crews—even sometimes by casual bystanders. In Lane’s lifetime, the following terms were commonly used for the schooner types he portrayed:

Fishing Schooners: While the port of Gloucester is synonymous with fishing and the schooner rig, Lane depicted only a few examples of fishing schooners in a Gloucester setting. Lane’s early years coincided with the preeminence of Gloucester’s foreign trade, which dominated the harbor while fishing was carried on from other Cape Ann communities under far less prosperous conditions than later. Only by the early 1850s was there a re-ascendency of the fishing industry in Gloucester Harbor, documented in a few of Lane’s paintings and lithographs. Depictions of fishing schooners at sea and at work are likewise few. Only A Smart Blow, c.1856 (inv. 9), showing cod fishing on Georges Bank (4), and At the Fishing Grounds, 1851 (not published), showing mackerel jigging on Georges Bank, are known examples. (5)

– Erik Ronnberg

References:

1. Howard I. Chapelle, The History of American Sailing Ships (New York: W.W. Norton & Co., 1935), 258. While three-masted schooners were in use in Lane’s time, none have appeared in his surviving work; and Charles S. Morgan, “New England Coasting Schooners”, The American Neptune 23, no. 1 (DATE): 5–9, from an article which deals mostly with later and larger schooner types.

2. John Lyman, “Register Tonnage and its Measurement”, The American Neptune V, nos. 3–4 (DATE). American tonnage laws in force in Lane’s lifetime are discussed in no. 3, pp. 226–27 and no. 4, p. 322.

3. Ship Registers of the District of Gloucester, Massachusetts, 1789–1875 (Salem, MA: The Essex Institute, 1944). Vessels whose shipping or fishing voyages included visits to foreign ports were required to register with the Federal Customs agent at their home port. While the vessel’s trade or work was unrecorded, their owners and master were listed, in addition to registry dimensions and place where built. Records kept by the National Archives can be consulted for information on specific voyages and ports visited.

4. Howard I. Chapelle, The National Watercraft Collection (Washington, DC: Smithsonian Institution, 1960), 74–76.

5. Howard I. Chapelle, The American Fishing Schooners (New York: W.W. Norton & Co., 1973), 58–75, 76–101.

artwork
Gloucester Harbor
Fitz Henry Lane
Gloucester Harbor
1852
Oil on canvas
28 x 48 1/2 in.
Cape Ann Museum, Gloucester, Mass., Deposited by the City of Gloucester, 1952. Given to the city by Mrs. Julian James in memory of her grandfather Sidney Mason, 1913 (DEP. 200)

Detail of fishing schooner.

[+]
photo (historical)
Cape Ann Scenery: No. 321 " Marine Study"
Heywood
c.1865
Stereograph card
Frank Rowell, Publisher
stereo image, "x " on card, "x"
Cape Ann Museum Library & Archive

View showing a sharpshooter fishing schooner, circa 1850. Note the stern davits for a yawl boat, which is being towed astern in this view.

Also filed under: Historic Photographs »

[+]
model
Model of fishing schooner "Amy Knight"
Model and photography by Erik A.R. Ronnberg, Jr.
Wood, metal hardware, cordage, paint
Model made for marine artist Thomas M. Hoyne
scale: 3/8" = 1'
Thomas M. Hoyne Collection, Mystic Seaport, Conn.

While this model was built to represent a typical Marblehead fishing schooner of the early nineteenth century, it has the basic characteristics of other banks fishing schooners of that region and period: a sharper bow below the waterline and a generally more sea-kindly hull form, a high quarter deck, and a yawl-boat on stern davits.

The simple schooner rig could be fitted with a fore topmast and square topsail for making winter trading voyages to the West Indies. The yawl boat was often put ashore and a "moses boat" shipped on the stern davits for bringing barrels of rum and molasses from a beach to the schooner.

– Erik Ronnberg

References:

Jeffrey Bolster, Black Jacks: African American Seafarers in the Age of Sail (Cambridge, MA: Harvard University Press, 1997).

Howard I. Chapelle, American Small Sailing Craft (New York: W.W. Norton & Co., 1951), 29–31.

Image: Erik Ronnberg

Also filed under: Hand-lining »   //  Ship Models »

[+]
illustration
Fishing Schooner sail plan, with overdrawing
Draftsman unknown; overdrawing attributed to Fitz Henry Lane
Pencil on paper in sail plan book titled William F. Davis, Gloucester 1845
20 x 14 in.
Cape Ann Museum Library & Archive, Gloucester, Mass.

The image, as originally drafted, showed only spars and sail outlines with dimensions, and an approximate deck line. The hull is a complete overdrawing, in fine pencil lines with varied shading, all agreeing closely with Lane's drawing style and depiction of water. Fishing schooners very similar to this one can be seen in his painting /entry:240/.

– Erik Ronnberg

[+]
publication
1842 Gloucester Telegraph 8.3.1842
8.3.1842
Newspaper
"Shipping Intelligence: Port of Gloucester"

"Fishermen . . . The T. [Tasso] was considerably injured by coming in contact with brig Deposite, at Salem . . ."

Image: Cape Ann Museum Library & Archive
[+]
publication
1857 Cape Ann Advertiser 10.1.1857
Procter Brothers
Various dates
Newsprint
From bound volume owned by publisher Francis Procter
Collection of Fred and Stephanie Buck

"A Prize Race—We have heard it intimated that some of our fishermen intend trying the merits of their "crack" schooners this fall, after the fishing season is done. Why not! . . .Such a fleet under full press of sail, would be worth going many a mile to witness; then for the witchery of Lane's matchless pencil to fix the scene upon canvass. . ."

Image: Collection of Fred and Stephanie Buck
[+]
PDF
view ]
publication
1865 Cape Ann Advertiser 7.7.1865
Article about new masthead, designed by Lane.
[+]
photo (historical)
Cape Ann Scenery: No. 114 Gloucester Harbor from Rocky Neck
John S. E. Rogers
c.1870
Stereograph card
Procter Brothers, Publisher
Cape Ann Museum Library & Archive

"Gloucester Harbor from Rocky Neck, Looking Southwest. This gives a portion of the Harbor lying between Ten Pound Island and Eastern Point. At the time of taking this picture the wind was from the northeast, and a large fleet of fishing and other vessels were in the harbor. In the range of the picture about one hundred vessels were at anchor. In the small Cove in the foreground quite a number of dories are moored. Eastern Point appears on the left in the background."

Southeast Harbor was known for being a safe harbor.

[+]
photo (historical)
Cape Ann Scenery: No. 82 View of Sch. "E. A. Horton"
Procter Brothers, Publisher
1870s
Stereograph card
Cape Ann Museum Library & Archive

"Said schooner was captured about the first of September, 1871, by Capt. Torry, of the Dominion Cutter 'Sweepstakes,' for alleged violation of the Fishery Treaty. She was gallantly recaptured from the harbor of Guysboro, N.S., by Capt. Harvey Knowlton., Jr., (one of her owners,) assisted by six brave seamen, on Sunday night, Oct. 8th. The Dominion Government never asked for her return, and the United States Government very readily granted her a new set of papers."

[+]
photo (historical)
Head of the Harbor, Gloucester
William A. Elwell
1876
Photograph
Cape Ann Museum Library & Archive
Image: Cape Ann Museum
[+]
photo (historical)
Inner Harbor, Gloucester
c.1870
Cape Ann Museum Library & Archive (2013.068)

Schooner fleet anchored in the inner harbor. Looking east from Rocky Neck, Duncan's Point wharves and Lane house (at far left), Sawyer School cupola on Friend Street.

[+]
illustration
Precursor to Gaff Rig of Schooners
Fitz H. Lane
In John J. Babson, History of the Town Gloucester (Gloucester, MA: Procter Brothers, 1860)

See p. 254.

As Erik Ronnberg has noted, Lane's engraving follows closely the French publication, Jal's "Glossaire Nautique" of 1848.

[+]
model
Shadow box model of Burnham Marine Railway
Erik Ronnberg
1997
Wood, cordage, acrylic paste, metal
~40 in. x 30 in.
Erik Ronnberg

Model shows mast of fishing vessel being unstepped.

Image: Erik Ronnberg
[+]
artwork
Silhouettes of vessel types
Charles G. Davis
Book illustrations from "Shipping and Craft in Silhouette" by Charles G. Davis, Salem, Mass. Marine Research Society, 1929. Selected images
[+]
artwork
Untitled (Ships Anchored in Gloucester Harbor)
D. Jerome Elwell
1892
Watercolor on paper
8 3/4 x 19 3/4 in.
Cape Ann Museum, Gloucester, Mass., Gift of Rev. and Mrs. A. A. Madsen, 1950
Accession # 1468

Fishing schooners in Gloucester's outer harbor, probably riding out bad weather.

Image: Cape Ann Museum
[+]
photo (historical)
View from Belmont House, of a fishing wharf, with the Old Fort of 1812 opposite
William A. Elwell
1876
Photograph
Cape Ann Museum Library & Archive

Ignatius Weber's windmill (now defunct) is shown.

Image: Cape Ann Museum
[+]
photo (historical)
Vincent's Cove
William Augustus Elwell
1876
Print from bound volume of Gloucester scenes sent to the Philadelphia Centennial Exhibition.
11 x 14 in.
Cape Ann Museum Library & Archives

Schooner "Grace L. Fears" at David A. Story Yard in Vincent's Cove.

[+]
[ top]

The term "ship," as used by nineteenth-century merchants and seamen, referred to a large three-masted sailing vessel which was square-rigged on all three masts. (1) In that same period, sailing warships of the largest classes were also called ships, or more formally, ships of the line, their size qualifying them to engage the enemy in a line of battle. (2) In the second half of the nineteenth century, as sailing vessels were replaced by engine-powered vessels, the term ship was applied to any large vessel, regardless of propulsion or use. (3)

Ships were often further defined by their specialized uses or modifications, clipper ships and packet ships being the most noted examples. Built for speed, clipper ships were employed in carrying high-value or perishable goods over long distances. (4) Lane painted formal portraits of clipper ships for their owners, as well as generic examples for his port paintings. (5)

Packet ships were designed for carrying capacity which required some sacrifice in speed while still being able to make scheduled passages within a reasonable time frame between regular destinations. In the packet trade with European ports, mail, passengers, and bulk cargos such as cotton, textiles, and farm produce made the eastward passages. Mail, passengers (usually in much larger numbers), and finished wares were the usual cargos for return trips. (6) Lane depicted these vessels in portraits for their owners, and in his port scenes of Boston and New York Harbors.

Ships in specific trades were often identified by their cargos: salt ships which brought salt to Gloucester for curing dried fish; tea clippers in the China Trade; coffee ships in the West Indies and South American trades, and  cotton ships bringing cotton to mills in New England or to European ports.  Some trades were identified by the special destination of a ship’s regular voyages; hence Gloucester vessels in the trade with Surinam were identified as Surinam ships (or barks, or brigs, depending on their rigs). In Lane’s Gloucester Harbor scenes, there are likely (though not identifiable) examples of Surinam ships, but only the ship "California" in his depiction of the Burnham marine railway in Gloucester (see Three Master on the Gloucester Railways, 1857 (inv. 29)) is so identified. (7)

– Erik Ronnberg

References:

1. R[ichard)] H[enry] Dana, Jr., The Seaman’s Friend, 13th ed. (Boston: Thomas Groom & Co., 1873), p. 121 and Plate IV with captions.

2. A Naval Encyclopaedia (Philadelphia: L. R. Hamersly & Co., 1884), 739, 741.

3.  M.H. Parry, et al., Aak to Zumbra: A Dictionary of the World’s Watercraft (Newport News, VA: The Mariners’ Museum, 2000), 536.

4. Howard I. Chapelle, The History of American Sailing Ships (New York: W.W. Norton & Co., 1935), 281–87.

5. Ibid.

6. Howard I. Chapelle, The National Watercraft Collection (Washington, DC: Smithsonian Institution, 1960), 26–30.

7. Alfred Mansfield Brooks, Gloucester Recollected: A Familiar History (Gloucester, MA: Peter Smith, 1974), 67–69.

Golden State
1884
Photograph
From American Clipper Ships 1833–1858, by Octavius T. Howe and Frederick C. Matthews, vol. 1 (Salem, MA: Marine Research Society, 1926).

Photo caption reads: "'Golden State' 1363 tons, built at New York, in 1852. From a photograph showing her in dock at Quebec in 1884."

[+]
photo (current)
"Friendship of Salem"
Built in 1998

A replica of an early nineteenth-century full-rigged ship.

[+]
artwork
Homeward Bound
c.1865
Hand-colored lithograph
Published by N. Currier, New York
Library of Congress (2002695891)
[+]
illustration
Ship
1885
Engraving from Merchant Vessels of the United States (Washington, DC: Government Printing Office)

Engraving of ship.

[+]
artwork
Packet "Nonantum" Riding out a Gale
Samuel Walters
1842
Oil on canvas
24 x 35 in.
Peabody Essex Museum, Salem, Mass.

Walters' painting depicts the "Nonantum" homeward bound for Boston from Liverpool in 1842. The paddle-steamer is one of the four Clyde-built Britannia-class vessels, of which one is visible crossing in the opposite direction.

Image: Peabody Essex Museum
[+]
illustration
Ship
Engraving in R. H. Dana, The Seaman's Friend, 13th ed. (Thomas Groom & Co. Publisher, 1873)

A ship is square-rigged throughout; that is, she has tops, and carries square sails on all three of her masts.

[+]
artwork
Silhouettes of vessel types
Charles G. Davis
Book illustrations from "Shipping and Craft in Silhouette" by Charles G. Davis, Salem, Mass. Marine Research Society, 1929. Selected images
[+]
[ top]

Sloops are one-masted sailing vessels which, in American examples, set fore-and-aft sails but usually no square sails. Thus, staysails, or jibs, are set from the fore stay(s) and a quadrilateral mainsail is set from the mast and spread by a gaff and a boom. The larger sloops would often set a triangular topsail over the main sail. (1)

The sloops depicted by Lane were used in various coastal trades, each with its own requirements, which dictated the sizes and details of their hulls and rigs. Most elegant were the packet sloops, which transported passengers, mail, and higher value goods between specific ports on regular schedules. They usually measured between sixty and seventy-five feet on deck, as dictated by anticipated shipping volume. Finely finished, they usually had stern galleries—a row of windows across the transom with ornamental moldings—and varied color schemes. Examples of packet sloops are in Gloucester Harbor from Rocky Neck, 1844 (inv. 14) (center, middle ground) and Study of Ships, 1851 (inv. 141) (foreground), both of which probably made trips between Gloucester and Boston, or Gloucester and Newburyport. (2)

Another specialized sloop of similar size was the stone sloop, used to ship granite blocks from stone-loading piers around Cape Ann to other ports. They were similar in rig to packet sloops, but of heavier construction with greater hold capacity and absence of decoration. Their stout appearance was augmented by simple color schemes, or even tarred topsides, reflecting the wear and strain imposed by their heavy cargos. Lane depicted these vessels in his painting of Fresh Water Cove from Dolliver's Neck, Gloucester, Early 1850s (inv. 45), with a sloop (at left) preparing to load at wharf-side, and another (at right) sailing out with a cargo. (3)

Sloops of the more work-a-day sort are the most commonly seen examples in Lane’s paintings, most of them appearing in his views of Boston Harbor. Usually deep-loaded and looking weather-worn, they contrast sharply with the packet- and clipper ships which dominate the scene. Sloops of this type are rarely seen in Lane’s paintings of Gloucester Harbor and the Maine coast, although they were certainly needed for short-distance transportation (see Bear Island, Northeast Harbor, 1855 (inv. 24), View of Camden Mountains from Penobscot Bay, c.1852 (inv. 207), Sunrise on the Maine Coast, Mount Desert Island, 1856 (not published)). For coastal Maine, lack of railroads for heavier freight and greater distances between ports made the use of schooners with larger carrying capacity a greater necessity. (4)

In Lane’s views of New York Harbor, a regional sloop variant, the Hudson River Sloop, appears in New York Harbor, c.1855 (inv. 46) (bow view, left) and A Calm Sea, c.1860 (inv. 6) (stern view, right). This type had become prominent in the Hudson River packet trade between New York City, Albany, and beyond to points north and west as far as the eastern terminus of the Erie Canal.  Large vessels for their rigs, they were well-finished and well-kept, reflecting pride of ownership and rivalry among their owners and crews. (5)

– Erik Ronnberg

References:

1. A Naval Encyclopaedia (Philadelphia: L.R. Hamersly & Co., 1884. Reprint: Detroit, MI: Gale Research Company, 1971), 59.  See first definition of "sloop" and definition of "sloop-rigged."

2. Robert Greenhalgh Albion, William A. Baker, and Benjamin Woods Labaree, New England and the Sea (Mystic, CT: Mystic Seaport Museum, 1972; reprinted in 1994), 127–28.

3. Howard I. Chapelle, The History of American Sailing Ships (New York: W.W. Norton & Co., 1935), 300–02.

4. Ibid., 300.

5. Ibid., 298–300.

illustration
Sloop
Engraving in R. H. Dana, The Seaman's Friend, 13th ed. (Thomas Groom & Co. Publisher, 1873)

A sloop has one mast, fore-and-aft rigged.

[+]
publication
Bermudian sloop
1884
A Naval Encyclopaedia:
Dictionary of nautical words and phrases
Special Articles on Naval Art and Science
Philadelphia: L.R. Hamersly & Co.

'Mudian, "Mugian, or Bermudian. A boat special to the Bermuda islands, usually decked, with the exception of a hatch; from 2 to 20 tons burden; it is short, of good beam, and great draft of water abaft, the stem and keel forming a curved line. It carries an immense quantity of ballast. Besides a long main- and short jib-boom, it has a long, taperking, raking mast, stepped just over the forefoot, generally unsupported by shrouds or stays; on it a jib-headed mainsail is hoisted to a height of twice, and sometimes three times, the length of the keel. This sail is triangular, stretched at its foot by a long boom. The only other sail is a small foresail or jib. They claim to be the fastest craft in the world for working to windward in smooth water, it being recorded of one that she made five miles dead to windward in the hour during a race; and though they may be laid over until they fill with water, they will not capsize.

[+]
artwork
Bermudian sloop in St. Georges Harbor, Bermuda
Edward James
c. 1864
St. George's Historical Society
Detail of painting of St. George's Harbour, Bermuda, during US Civil War, with a Confederate blockade runner anchored in the foreground.

Also filed under: Puerto Rico »

[+]
object
Scale model of stone sloop "Albert Baldwin"
William Niemi
c.1940
Wood, metal, cordage, cloth, paint.
Scale: ¼ in. = 1ft. (1:48)
Cape Ann Museum. Gift of Roland and Martta Blanchet (1997.17.3)

Although built in 1890 and larger than the stone sloops of Lane’s time, the "Albert Baldwin’s" hull form, rig, and loading boom are very similar to those of the 1840s and 1850s.

[+]
artwork
Silhouettes of vessel types
Charles G. Davis
Book illustrations from "Shipping and Craft in Silhouette" by Charles G. Davis, Salem, Mass. Marine Research Society, 1929. Selected images
[+]
[ top]

The term “wherry”—variously spelled—has a long history with many hull types, some dating from the fifteenth century. (1) The version known to Lane appears to be a variant of the dory hull form and probably was developed by French and English fishermen in the Newfoundland fisheries before 1700. (2) From that time, the wherry and the dory co-evolved, their similarities the result of their construction, their differences the result of use. By the early nineteenth century, their forms reached their final states, if fragments of contemporary descriptions are any indication. (3)

By the time Lane was depicting wherries, the type (as used for fishing) resembled a larger, wider version of a dory. The extra width was due to greater bottom width (both types had flat bottoms), with a wider transom at the stern instead of the narrow, v-shaped “tombstone.” These features are easy to see in one of his drawings (see Three Men, One in a Wherry (inv. 225)) and a painting (see Sunrise through Mist, 1852 (inv. 98)), the latter depicted alongside a dory, clearly showing the differences.

No published descriptions of the uses of wherries on Cape Ann in Lane’s time have come to light, but an example in broadside view offers one use. In Becalmed Off Halfway Rock, 1860 (inv. 344), a pinky (in right foreground) has a dory and a wherry in tow, the latter loaded with a gill net for catching mackerel. (4) The greater size of the wherry is required for stowing the net, as well as setting it while the dory tows away one end to set it in way of the mackerel school.

In Lane’s time, wherries would have been used where bulky gear was called for in the coastal fisheries, i.e. gill nets, and fish traps such as pound nets, fyke nets, and lobster traps. Migrating fish schools (herring, mackerel) and shellfish were the target species.

The dory’s development was first dictated by its use in shore fishing, where small size and light weight made it easy to maneuver around rocks and shallows, and to haul ashore at the end of a day’s work. Its simple design made it easy and cheap to build. This is borne out by the standardized construction and sizes used by Simon Lowell’s boat shop at Salisbury Point, Massachusetts at the turn of the nineteenth century. Lowell called his boats “wherries,” but in Swampscott, Massachusetts, the fishermen, who used them called them “dories,” which may mark the beginning of the latter term’s wider use. (5)

The dories we see in Lane’s paintings are in virtually every way like the ones we know today. One of the best examples (see View from Kettle Cove, Manchester-by-the-Sea, 1847 (inv. 94)) even shows interior detail, including frames, leaving no doubt about its construction. Other good examples are found in Salem Harbor, 1853 (inv. 53), View of Gloucester Harbor, 1848 (inv. 97), and Sunrise through Mist, 1852 (inv. 98).

For inshore fishing, dories were used to catch mackerel and herring, either with hook and line or with small nets. Hooks and line were used for flat fish (flounder, dab, and fluke), rock cod, hake, and cunner. Eels were speared (see View from Kettle Cove, Manchester-by-the-Sea, 1847 (inv. 94)), clams were dug, and lobsters trapped. In Lane’s later years, the use of dories in trawling (setting long “trawl lines” with many baited hooks) was in its earliest. This method required six to ten dories carried on board a schooner to fish on the distant banks off New England and Canada. Early records of dory trawling in New England are fragmentary, giving the mid-1840s as the time of introduction. (6) The Gloucester-owned schooner "Anna"  made a successful dory trawling trip to the Grand Banks in 1854, but no depiction of this vessel by Lane has been found or recorded. (5) Despite successful early efforts, dory trawling from Gloucester was slow to be accepted, and the fishery had very limited growth prior to 1860. (7)

– Erik Ronnberg

References:

1. M.H. Parry et al., Aak to Zumbra (Newport News, VA: The Mariners’ Museum, 2000), 634.

2. John Gardner, The Dory Book (Camden, ME: International Marine Publishing Company, 1978), 5–9.

3. Ibid., 25–29.

4. John Wilmerding, ed., Paintings by Fitz Hugh Lane (Washington, DC: National Gallery of Art, 1988), 89, 92. The “possibly discarded whaleboat” is definitely a wherry.

5. Gardner, 9, 10.

6. Wesley George Pierce, Goin’ Fishin’ (Salem, MA: Marine Research Society, 1934), 63–64.

7. Raymond McFarland, A History of New England Fisheries (Philadelphia: University of Pennsylvania, 1911), 279.

photo (historical)
Lobsterman's dory beached at Salt Island
Martha Hale Harvey
1890s
Photograph
Cape Ann Museum Library & Archive
[+]
photo (historical)
Cape Ann Scenery: No. 114 Gloucester Harbor from Rocky Neck
John S. E. Rogers
c.1870
Stereograph card
Procter Brothers, Publisher
Cape Ann Museum Library & Archive

"Gloucester Harbor from Rocky Neck, Looking Southwest. This gives a portion of the Harbor lying between Ten Pound Island and Eastern Point. At the time of taking this picture the wind was from the northeast, and a large fleet of fishing and other vessels were in the harbor. In the range of the picture about one hundred vessels were at anchor. In the small Cove in the foreground quite a number of dories are moored. Eastern Point appears on the left in the background."

Southeast Harbor was known for being a safe harbor.

[+]
model
Model of the pinky "Essex" with dory and wherry alongside
Model and photography by Erik A.R. Ronnberg, Jr.
[+]
illustration
Hull chart
In Howard I. Chappelle, American Small Sailing Craft (New York: Norton, 1951), p. 154

See fig. 56.

[+]
model
Joseph A. Proctor (Gloucester, MA) fisherman's dory
Wood
Gloucester, MA
4 x 33 1/2 x 7 1/4 in (10.16 x 85.09 x 18.415 cm)
Peabody Essex Museum
Image: Peabody Essex Museum

Also filed under: Objects »   //  Ship Models »

[+]
[ top]

Packet shipping was conducted by vessels of many types in many regions over the last four centuries, but the packets depicted by Lane were the products of nineteenth-century mercantilism and the Industrial Revolution. The packets sailing out of Boston and New York for European ports were large vessels, invariably ship-rigged, and if not as sharp-ended as clipper ships, had sufficiently fine hull forms to make fast, if not record, passages.

A packet ship's highest priority was delivery of mail on a regular schedule. Passengers and high-value trade goods occupied the considerable remaining hold space. This was particularly true of west-bound passages, which brought fine European wares and throngs of immigrants to America. East-bound passages brought professionals, students, travelers, and high-value raw and semi-finished materials to European ports, mainly Britain and France, and to a lesser extent, the Netherlands and Germany.

East-bound cargos were dominated by southern products - baled cotton, rice, tobacco, and naval stores. These were delivered to New York and other northern ports by coastal packets (mainly brigs and small ships) for transatlantic shipment. Northern products included flaxseed, iron ore, fruit, wool, hides, and flour. Delivery times were on average well within 30 days, giving credence to the packet lines' promise of scheduled delivery.

West-bound passages, which meant sailing against the wind, took longer—34 to 40 days on average, depending on the port of departure. Cargos and passengers were a far more varied lot with little of the consistency of east-bound counterparts.

Lane's paintings depict Boston and New York packet ships in the peak years of their employment. The Civil War, coupled with the development of reliable steam engines for marine propulsion, posed challenges the sailing ship could not overcome. Coastal packet lines went quickly, the transatlantic lines lasting into the 1870s.

– Erik Ronnberg

Reference:

Robert G. Albion, Square-Riggers on Schedule (Princeton, NJ: Princeton University Press, 1938).

Related tables: Ship (Full-Rigged) »  //  Sloop »
photo (historical)
Black Ball Packet Ships in New York Harbor
Anthony Brothers
1860
Photograph
Johnson, H. and Lightfoot, F.S.: Maritime New York in Nineteenth-Century Photographs, Dover Publications, Inc., New York

Also filed under: New York Harbor »

[+]
artwork
Packet "Nonantum" Riding out a Gale
Samuel Walters
1842
Oil on canvas
24 x 35 in.
Peabody Essex Museum, Salem, Mass.

Walters' painting depicts the "Nonantum" homeward bound for Boston from Liverpool in 1842. The paddle-steamer is one of the four Clyde-built Britannia-class vessels, of which one is visible crossing in the opposite direction.

Image: Peabody Essex Museum
[+]
[ top]

Nathaniel Silsbee (1804–81) bought Salem Harbor, 1853 (inv. 53) from Lane in 1853. His family's ship is in the painting. (1)

Nathaniel was the son of Nathaniel (1773-1850) and Sarah (Becket) Silsbee. Nathaniel, Sr. was a shipmaster, merchant and statesman. He became so successful that he was able to retire as a captain in 1801 at the age of twenty eight. He went on to purchase shares in vessels on his own account and on that of the firm of Silsbee, Pickman, and Stone. He served in both the United States House of Representatives and the United States Senate.

Nathaniel Jr. was married to Marianne (Devereux) Silsbee (1812–89). He was the mayor of Salem (1849–50) and treasurer of Harvard College (1862–76).

(1) Lawrence W. Jenkins, A Catalogue of the Charles H. Taylor Collection of Ship Portraits in the Peabody Museum of Salem (Salem, MA: Peabody Museum, 1949).

Exhibition History

1966 DeCordova Museum: DeCordova Museum, Lincoln, Massachusetts, Fitz Hugh Lane: The First Major Exhibition, no. 41.
1974 Farnsworth Art Museum: William A. Farnsworth Library and Art Museum, Rockland, Maine, Fitz Hugh Lane, 1804–1865, no. 29.
1980 National Gallery of Art: National Gallery of Art, Washington, District of Columbia, American Light: The Luminist Movement, 1850–1875.
1986–87 National Museum: National Museum, Stockholm, A New World: American Landscape Painting, 1893–1900.
1988 National Gallery of Art: National Gallery of Art, Washington, District of Columbia, Paintings by Fitz Hugh Lane, no. 27, ill. in color, p. 52.
2002 Ambassador's Residence, Ireland: United States Ambassador's Residence, Dublin, Art of New England, 1770–1954.

Published References

American Neptune 1965: The American Neptune, Pictorial Supplement VII: A Selection of Marine Paintings by Fitz Hugh Lane, 1804–1865, plate XXI, no. 78. ⇒ includes text
Wilmerding 1966a: Fitz Hugh Lane: The First Major Exhibition, no. 41. ⇒ includes text
Museum of Fine Arts, Boston 1969: American Paintings in the Museum of Fine Arts, Boston.
Wilmerding 1971a: Fitz Hugh Lane.
Wilmerding 1974: Fitz Hugh Lane, 1804–1865, no. 29.
Wilmerding 1980a: American Light: The Luminist Movement, 1850–1875, fig. 111, p. 109, text, p. 111.
Wilmerding 1980c: "American Light: The Luminist Movement, 1850–1875; An Exhibition at the National Gallery of Art."
Hoffman 1983: "The Art of Fitz Hugh Lane," p. 33.
Stockholm 1986: En Ny värld : amerikanskt landskapsmåleri 1830-1900 och ett urval samtida skandinaviskt landskapsmåleri. A New World: American landscape painting 1830-1900 and a selection of contemporary Scandinavian landscape painting.
Wilmerding 1988a: Paintings by Fitz Hugh Lane, no. 27, ill. in color, p. 53.
Wilmerding 2005: Fitz Henry Lane, pl. vi.
Craig 2006a: Fitz H. Lane: An Artist's Voyage through Nineteenth-Century America, fig. 108, text, p. 170.
Wilmerding 2007a: Fitz Henry Lane & Mary Blood Mellen: Old Mysteries and New Discoveries, fig. 5, p. 17. ⇒ includes text
view all »

Interactive feature

Related historical materials

Other Locales
Vessel Types
Maritime & Other Industries & Facilities
People
Citation: "Salem Harbor, 1853 (inv. 53)." Fitz Henry Lane Online. Cape Ann Museum. http://fitzhenrylaneonline.org/catalog/entry.php?id=53 (accessed May 26, 2017).
Record last updated May 8, 2017. Please note that the information on this and all pages is periodically reviewed and subject to change.
Please share your knowledge with us: click here to leave feedback.
